Engineering and remote access
3.5 Cyclic and acyclic data
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
93
Index
Slot
Subslot
Data set
Type
Description
Data size
0x0044 0 1 NTP client status pa-
rameters
Reading Status NTP client 40 bytes
(from V2.2)
0x0045 0 1 PROFINETSecurity Reading/
writing
Setting for DCP write protection 2 bytes
(from V2.2)
You can find detailed information about the individual data sets in Section Data sets
(Page 93)
3.5.2.1
Data sets
In this section you can find detailed information about the individual data sets that are sent
from the PROFINET IO-Controller to the SITOP UPS1600 - and which can be read from the
SITOP UPS1600.
0x0001: Buffering parameters (reading/writing)
Data
Description
Data type
Buffer time [1 s] Buffer time: After the selected buffer time has expired, the
SITOP UPS1600 switches off the load output. The actual buffer
time that can be achieved depends on the connected loads and
energy storage devices.
Unsigned16
Buffer time 2 [1 s] Additional buffer time after the PC was shut down. (only valid in
conjunction with PC software SITOP UPS Manager)
Unsigned16
Buffer threshold [0.01 V] Connection threshold: Switching voltage for buffering. Buffering is
active below this value.
Unsigned16
Stop buffering voltage [0.01 V]
Buffer operation is exited if the battery voltage is below this value.
Unsigned16
Input voltage OK time [1 ms] Wait time for stable input voltage: Minimum time during which the
input voltage during buffer operation must be available at the
SITOP UPS1600 to exit buffer operation of the SITOP UPS1600
and to again supply the connected loads via the input voltage
(normal operation).
Unsigned16
Downtime alarm [1 ms] Downtime alarm: Alarm filter: An alarm is only sent if it is active for
longer than the set time.
Unsigned16
Buffering allowed Activate or deactivate buffer operation. The setting is only accept-
ed in operating mode Remote Enable (REN) of the
SITOP UPS1600.
Unsigned8
Enable reset after buffering Enable reset after buffering: If, during buffer operation, the input
voltage becomes available again, then the output is switched off
for a selectable time in order to reset the connected devices.
Unsigned8
