Engineering and remote access
3.5 Cyclic and acyclic data
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
91
Battery change
recommended
Battery replacement recommend-
ed: Battery capacity is insufficient
to achieve the specified buffer
time:
• 0: no
• 255: yes
Unsigned8
Battery charge level Battery charge level in %:
• 0-100: 0-100%
• 255: unknown battery
Unsigned8
Battery connection
maintenance
from V2.1
Connection to the battery inter-
rupted: Check the connection and
fuse:
• 0: no maintenance required
• 255: maintenance required
Unsigned8
Reading and writing data sets
An overview of all data sets, which are communicated between the SITOP UPS1600 and the
PROFINET IO-Controller is provided in the following table. Here, a distinction is made
between the following data sets:
●
Data which is sent from the SITOP UPS1600 to the
PROFINET IO-Controller .
●
Data which is sent from the PROFINET IO-Controller to the
SITOP UPS1600.
0x0001 0 1 Buffering parameters Reading /
writing
Buffer parameters.
14 bytes
0x0002 0 1 Battery parameters Reading /
Parameters of the connected battery
5 bytes
0x0003 0 1 Charging parameters Reading /
Charge parameters of the connected
4 bytes
0x0004 0 1 Reset parameters Reading /
Reset parameters. 1 byte
0x0005 0 1 Battery information
parameters
Reading
Information about the connected battery
modules SITOP UPS1100. This infor-
mation is available via the link "Energy
1024 bytes
0x0006 0 1 Device information
Reading Information about the
148 bytes
0x0007 0 1 Hardware settings
parameters
Reading Hardware settings of the
SITOP UPS1600 (settings that were
made at the front of the device).
8 bytes
