Engineering and remote access
3.3 SIMATIC STEP 7 in the TIA Portal
SITOP UPS1600 / UPS1100
58 Manual, 04.2017, A5E37775406-8-76
Parameterizing the UPS1600
The adjustable parameters of the SITOP UPS1600 can be found in STEP 7 in the TIA Portal
in the inspector window under Properties when the appropriate device was selected.
For parameterization, in the area navigation, the settings under "Base Unit", "Energy
storage" and "Webserver" are relevant.
DCP write protection activated
Base Unit Buffering All parameters, which involve the behavior of SITOP UPS1600 when
buffering
Setting of the alarm signaling and the wait time for stable input voltage.
Parameters for the battery modules used
Web server General information Define as to whether the SITOP UPS1600 may be accessed via web
server (yes / no)
Activate web server on this module
Enable automatic logoff
Activate automatic update / Activation interval
OPC UA server OPC UA server acti-
Here, activate the OPC UA server.
Unencrypted access
You have the option of activating unencrypted access to the
OPC UA server. However, this option is not recommended.
Specify which port should be used.
NTP client
Here, activate the NTP client.
NTP server
Enter up to 4 addresses for an NTP server.
A detailed description of the individual parameters of the subgroups is contained in the
associated section under Parameterizing the UPS in STEP 7 in the TIA Portal (Page 58).
The procedure is the same for all parameters. This section describes the general procedure
to reach the configuration dialog, using as example the parameters for buffering. The
individual parameters and their possible values are described in the following subsections.
Each parameter has a start value. A click on "Reset to initial values" resets all parameters of
a subgroup to the associated start value.
● The SITOP UPS1600 was integrated in the opened project.
