Technical data
8.7 Mechanical system
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
217
8.7
Mechanical system
8.7.1
SITOP UPS1600
Table 8- 4 SITOP UPS1600 10 A / 20 A
6EP4134-3AB00- ... (10 A)
6EP4136-3AB00- ... (20 A)
... -0AY0
... -1AY0
... -2AY0
... -0AY0
... -1AY0
... -2AY0
Connection system
Screw-type terminal
Connections / DC input
IN+, IN-: 1 screw terminal each for 0.2 - 6 (4) mm² solid (finely stranded)
Connections / DC output
OUT+, OUT-: 1 screw terminal each for 0.2 - 6 (4) mm² solid (finely stranded)
Connections / BAT
BAT+, BAT-: 1 screw terminal each for 0.2 - 6 (4) mm² solid (finely stranded)
Connections / signal con-
nector
X2 (1 - 14): 1 screw terminal each for 0.2 - 1.5 mm² solid/finely stranded
Width of the housing
50 mm
50 mm
50 mm
50 mm
50 mm
50 mm
Height of the housing
138.7 mm
138.7 mm
138.7 mm
138.7 mm
138.7 mm
138.7 mm
Depth of the housing
125 mm
125 mm
125 mm
125 mm
125 mm
125 mm
Installation width
50 mm
50 mm
50 mm
50 mm
50 mm
50 mm
Mounting height
238.7 mm
238.7 mm
238.7 mm
238.7 mm
238.7 mm
238.7 mm
Weight, approx.
0.38 kg
0.4 kg
0.44 kg
0.39 kg
0.41 kg
0.45 kg
Product feature /
of the housing /
housing that can be lined
up next to one another
Yes
Type of mounting /
wall mounting
No
Type of mounting /
rail mounting
Yes
Type of mounting /
S7-300 rail
mounting
No
Mounting Can be snapped onto standard TH35x7,5/15 mounting rails (EN 60715)
Table 8- 5 SITOP UPS1600 40 A
6EP4137-3AB00- ... (40 A)
... -0AY0
... -1AY0
... -2AY0
Connection system
Screw-type terminal
Connections / DC input
IN+, IN-: 1 screw terminal each for 0.5 - 16 (4) mm² solid (finely stranded)
Connections / DC output
OUT+, OUT-: 1 screw terminal each for 0.5 - 16 (4) mm² solid (finely stranded)
Connections / BAT
BAT+, BAT-: 1 screw terminal each for 0.5 - 16 (4) mm² solid (finely stranded)
