Technical data
8.7 Mechanical system
SITOP UPS1600 / UPS1100
218 Manual, 04.2017, A5E37775406-8-76
6EP4137-3AB00- ... (40 A)
... -0AY0
... -1AY0
... -2AY0
Connections / signal con-
nector
X2 (1 - 14): 1 screw terminal each for 0.2 - 1.5 mm² solid/finely stranded
Width of the housing
70 mm
70 mm
70 mm
Height of the housing
138.7 mm
138.7 mm
138.7 mm
Depth of the housing
150 mm
150 mm
150 mm
Installation width
70 mm
70 mm
70 mm
Mounting height
238.7 mm
238.7 mm
238.7 mm
Weight, approx.
0.65 Kg
0.65 Kg
0.7 kg
Product feature /
of the housing /
housing that can be lined
up next to one another
Yes
Type of mounting /
wall mounting
No
Type of mounting /
rail mounting
Yes
Type of mounting /
S7-300 rail mounting
No
Mounting
Can be snapped onto standard TH35x7,5/15 mounting rails (EN 60715)
8.7.2
SITOP UPS1100
Table 8- 6 SITOP UPS1100 1.2 Ah / 2.5 Ah / 3.2 Ah
6EP4131-0GB00- ...
(1.2 Ah)
6EP4132-0GB00- ...
(2.5 Ah)
6EP4133-0GB00- ...
(3.2 Ah)
Connection system
Screw-type terminal
Connections / DC input
X1-1, X1-2: 1 screw terminal each for 0.2 - 6 (4) mm² solid (finely stranded)
Connections / signal terminal
X2-1, X2-2: 1 screw terminal each for 0.14 - 4 (2.5) mm² solid (finely stranded)
Width of the housing 89 mm 265 mm 190 mm
Height of the housing 130.3 mm 115 mm 169.3 mm
Depth of the housing
106.7 mm
76 mm
78.7 mm
Installation width
89 mm
265 mm
190 mm
Mounting height
145.3 mm
130 mm
184.3 mm
Weight, approx.
1.9 kg
3.7 kg
3.8 kg
Product feature /
of the housing /
housing that can be lined up
next to one another
Yes
Type of mounting /
wall mounting
Yes
