Parameter
A.1 MMDiag block parameter
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
235
Parameter
Data format
Default setting
Meaning
ExtMsg2 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External Message 2
ExtMsg3 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External Message 3
ExtVa105
ANY
–
External Value 5
ExtVa106
ANY
–
External Value 6
ExtVa107
ANY
–
External Value 7
ExtVa108
ANY
–
External Value 8
ExtVa109
ANY
–
External Value 9
ExtVa110
ANY
–
External Value 10
ReserveIn
WORD
16#00
Reserved
Output parameters
Table A- 2 Output parameter MMDiag
Parameter
Data format
Default setting
Meaning
GrpErr STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Group error is active
RackF_Act STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Rack failure
ModF_Act STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Module Failure
Rack1Err STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = DP slave/IO system failure (primary)
Rack2Err STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = DP slave/IO system failure (redundant)
BusFlt
BOOL
FALSE
1 Connection fault
RdEn
BOOL
FALSE
1 = Enable read data record
RdErr STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Error read record
RdErrStat
WORD
16#00
Status of Read record error
