5.2.2 Selecting a tool
Procedure
1. Select the "JOG" operating mode.
2. Press the "T, S, M" softkey.
3. Enter the name or the number of the tool T in the input field.
- OR -
Press the "Select tool” softkey.
The tool selection window opens.
Place the cursor on the desired tool and press the "OK" softkey.
The tool is transferred to the "T, S, M... window" and displayed in the field
of tool parameter "T".
4. Select tool edge D or enter the number directly in field "D".
5. Select the sister tool ST or enter the number directly into the "ST" field
6. Press the <CYCLE START> key.
The tool is loaded into the spindle.
5.2.3 Starting and stopping a spindle manually
Procedure
1. Select the "JOG" operating mode.
2. Press the "T, S, M" softkey.
3. Select the desired spindle (e.g. S1) and enter the desired spindle speed
(rpm) or the constant cutting velocity (m/min) in the adjacent input field.
The spindle remains stationary.
Execution in manual mode
5.2 Selecting a tool and spindle
Milling
166 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
