4. Press the "New cutting edge" softkey.
A new data set is stored in the list.
The cutting edge number is incremented by one and the offset data is
assigned the values of the cutting edge on which the cursor is positioned.
5. Enter the offset data for the 2nd cutting edge.
6. Repeat this process if you wish to create more tool edge offset data.
7. Position the cursor on the cutting edge that you want to delete and press
the "Delete cutting edge" softkey.
The data set is deleted from the list. The first tool cutting edge cannot be
deleted.
13.5.5 Delete tool
Tools that are no longer in use can be deleted from the tool list for a clearer overview.
Procedure
1. The tool list is opened.
2. Place the cursor on the tool that you would like to delete.
3. Press the "Delete tool" softkey.
A safety prompt is displayed.
4. Press the "OK" softkey if you really want to delete the tool.
Use this softkey to delete the tool.
If the tool is in a magazine location, it is unloaded and then deleted.
Multiple load points - tool in magazine location
If you have configured several loading points for a magazine, then the "Loading Point
Selection" window appears after pressing the "Delete tool" softkey.
Select the required load point and press the "OK" softkey to unload and delete the tool.
13.5.6 Loading and unloading tools
You can load and unload tools to and from a magazine via the tool list. When a tool is loaded,
it is taken to a magazine location. When it is unloaded, it is removed from the magazine and
stored in the NC memory.
When you are loading a tool, the application automatically suggests an empty location. You
may also directly specify an empty magazine location.
Tool management
13.5 Tool list
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 705
