Procedure
1. The part program or ShopMill program to be processed has been created
and you are in the editor.
2. Press the "Drilling" softkey.
3. Press the "Boring" softkey.
The "Boring" input window opens.
Parameters, G code program Parameters, ShopMill program
PL Machining plane T Tool name
RP Retraction plane mm D Cutting edge number
SC Safety clearance mm F Feedrate mm/min
mm/rev
S / V Spindle speed or constant cutting
rate
rpm
m/min
Parameter Description Unit
Machining posi‐
tion (only for G
code)
● Single position
Drill hole at programmed position
● Position pattern
Position with MCALL
Z0 (only for G
code)
Reference point Z mm
DIR
(only for G
code)
Direction of rotation
●
●
Z1 Drilling depth (abs) or drilling depth in relation to Z0 (inc) mm
DT
● Dwell time at final drilling depth in seconds
● Dwell time at final drilling depth in revolutions
s
rev
SPOS Spindle stop position Degrees
Lift mode
● Do not lift off contour
The cutting edge is not fully retracted, but traverses back to the retraction plane.
● Lift
The cutting edge retracts from the edge of the hole and then retracts to the safety
clearance from the reference point and then positions at the retraction plane and hole
center point.
DX (only G Code) Retraction distance in the X direction (incremental) - (for lift only) mm
DY (only G code) Retraction distance in the Y direction (incremental) - (for lift only) mm
DZ (only G code) Retraction distance in the Z direction (incremental) - (for lift only) mm
D (only ShopMill) Retraction distance (incremental) - (for lift only) mm
Programming technological functions (cycles)
10.1 Drilling
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 395
