Parameter Description
DXY
Maximum plane infeed
Maximum plane infeed as a percentage of the milling cutter diameter
- (only for ∇ and ∇∇∇)
mm
%
DZ Maximum depth infeed – (only for ∇, ∇∇∇ or ∇∇∇ edge) mm
UXY Plane finishing allowance – (only for ∇, ∇∇∇ or ∇∇∇ edge) mm
UZ Depth finishing allowance – (only for ∇ or ∇∇∇) mm
Insertion The following insertion modes can be selected – (only for ∇, ∇∇∇ or ∇∇∇ edge):
Predrilled: (only for G code)
With G0, the pocket center point is approached at the retraction plane level, and
then, from this position, also with G0, the axis travels to the reference point brought
forward by the safety clearance. The machining of the rectangular pocket is then
performed according to the selected insertion strategy, taking into account the
programmed blank dimensions.
Perpendicular: Insert vertically at the center of pocket
The tool executes the calculated actual depth infeed at the pocket center in a single
block. This setting can be used only if the cutter can cut across center or if the pocket
has been predrilled.
Helical: Insert along helical path
The cutter center point traverses along the helical path determined by the radius and
depth per revolution (helical path). If the depth for one infeed has been reached, a
full circle motion is executed to eliminate the inclined insertion path.
Oscillating: Insert with oscillation along center axis of rectangular pocket
The cutter center point oscillates back and forth along a linear path until it reaches the
depth infeed. When the depth has been reached, the path is traversed again without
depth infeed in order to eliminate the inclined insertion path.
FZ
(only for G code)
Depth infeed rate – (only for vertical insertion) *
FZ
(only for ShopMill)
Depth infeed rate – (only for vertical insertion) mm/min
mm/tooth
EP Maximum pitch of helix – (for helical insertion only) mm/rev
ER Radius of helix – (for helical insertion only)
The radius cannot be any larger than the cutter radius; otherwise, material will remain.
mm
EW Maximum insertion angle – (for insertion with oscillation only) Degrees
FS Chamfer width for chamfering - (only for chamfering) mm
ZFS Insertion depth of tool tip (abs or inc) – (only for chamfering) mm
* Unit of feedrate as programmed before the cycle call
Programming technological functions (cycles)
10.2 Milling
Milling
428 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
