Parameter Description
FZ (only for G code) Depth infeed rate *
Machining The following machining operations can be selected:
● ∇ (roughing)
● ∇∇∇ (finishing)
● ∇∇∇ edge (edge finishing)
● Chamfering
X0
Y0
Z0
The positions refer to the reference point:
Reference point X
Reference point Y
Reference point Z
mm
mm
mm
∅ Diameter of blank spigot mm
N Number of edges
SW or L Width across flats or edge length mm
R1 and FS1 Rounding radius or chamfer width
Z1 Multi-edge depth (abs) or depth in relation to Z0 (inc) - (only for ∇, ∇∇∇ and ∇∇∇ edge) mm
DXY
● Maximum plane infeed
● Maximum plane infeed as a percentage of the milling cutter diameter
- (only for ∇ and ∇∇∇)
mm
%
DZ Maximum depth infeed – (only for ∇ and ∇∇∇) mm
UXY Plane finishing allowance - (only for ∇, ∇∇∇ and ∇∇∇ edge) mm
UZ Depth finishing allowance (only for ∇ and ∇∇∇) mm
FS Chamfer width for chamfering - (for chamfering only) mm
ZFS Insertion depth of tool tip (abs or inc) - (for chamfering only) mm
* Unit of feedrate as programmed before the cycle call
Hidden parameters
The following parameters are hidden. They are pre-assigned fixed values or values that can
be adjusted using setting data.
Parameter Description Value Can be set in SD
PL (only for G code) Machining plane Defined in MD
52005
SC (only for G
code)
Safety clearance 1 mm x
Machining
position
Mill multi-edge at the programmed position (X0, Y0, Z0). Single posi‐
tion
α0 Angle of rotation 0°
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Programming technological functions (cycles)
10.2 Milling
Milling
448 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
