Parameter Description
Machining The following machining operations can be selected:
● ∇ (roughing)
● ∇∇ (pre-finishing)
● ∇∇∇ (finishing)
● ∇∇∇ base (base finishing)
● ∇∇∇ edge (edge finishing)
● Chamfering
Technology
● Vortex milling
The milling cutter performs circular motions along the length of the slot and back
again.
● Plunge cutting
Sequential drilling motion along the tool axis.
Milling direction: - (except plunge cutting).
● Climbing cutting
● Conventional cutting
● Climbing-conventional cutting
X0
Y0
Z0
The positions refer to the reference point:
Reference point X
Reference point Y
Reference point Z
mm
mm
mm
W Slot width
L Slot length mm
Z1 Slot depth (abs) or depth in relation to Z0 (inc) mm
DXY
● Maximum plane infeed
● Maximum plane infeed as a percentage of the milling cutter diameter- (only for ∇ and
∇∇∇)
mm
%
DZ Maximum depth infeed - (only for ∇, ∇∇ pre-finishing, ∇∇∇ and ∇∇∇ edge)- (only for vortex
milling)
mm
UXY Plane finishing allowance (slot base) - (only for ∇, ∇∇ pre-finishing and ∇∇∇ base) mm
UZ Plane finishing allowance (slot edge) - (only for ∇, ∇∇ pre-finishing and ∇∇∇ edge) mm
FS Chamfer width for chamfering (inc) - (for chamfering only) mm
ZFS Insertion depth of tool tip (abs or inc) - (for chamfering only) mm
* Unit of feedrate as programmed before the cycle call
Programming technological functions (cycles)
10.2 Milling
Milling
468 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
