Parameter Description Unit
UXY Plane finishing allowance – (only for ∇, ∇∇∇ base or ∇∇∇ edge) mm
UZ Depth finishing allowance – (only for ∇ or ∇∇∇ base) mm
Lift mode Lift mode before new infeed
If the machining operation requires several points of insertion, the retraction height to
which the tool is retracted, is selected as follows:
● To retraction plane
● Z0 + safety clearance
If there are no elements larger than Z0 (X0) in the pocket area, then Z0 (X0) + safety
clearance can be programmed as the lift mode.
mm
mm
mm
FS Chamfer width for chamfering - (only for chamfering machining) mm
ZFS Insertion depth of tool tip (abs or inc) - (for machining only) mm
Parameters in the "Input simple" mode
G code program parameters ShopMill program parameters
Input
● simple
PRG Name of the program to be generated T Tool name
Milling direction
● Climbing
cutting
● Conventional
cutting
D Cutting edge number
RP Retraction plane mm F Feedrate mm/min
mm/rev
F Feedrate * S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter Description
Machining The following machining operations can be selected:
● ∇ (roughing)
● ∇∇∇ base (base finishing)
● ∇∇∇ edge (edge finishing)
● Chamfering
Z0 Reference point in the tool axis Z mm
Z1 Spigot depth (abs) or depth relative to Z0 (inc) - (only for ∇, ∇∇∇ base and ∇∇∇ edge) mm
DXY
● Maximum plane infeed
● Maximum plane infeed as a percentage of the milling cutter diameter- (only for ∇ and
∇∇∇ base)
mm
%
DZ Maximum depth infeed – (only for ∇ and ∇∇∇ edge) mm
UXY Plane finishing allowance - (only for ∇, ∇∇∇ base or ∇∇∇ edge) mm
Programming technological functions (cycles)
10.3 Contour milling
Milling
510 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
