Parameter Description Unit
X0 Reference point X from thread table ∅ (abs) mm
Z0 Reference point Z (abs) mm
P0 Thread pitch 1 mm
X1 or
X1α
● Intermediate point 1 X ∅ (abs) or
● Intermediate point 1 in relation to X0 (inc) or
● Thread taper 1
Incremental dimensions: The sign is also evaluated.
mm
Degrees
Z1
● Intermediate point 1 Z (abs) or
● Intermediate point 1 in relation to Z0 (inc)
mm
P1 Thread pitch 2 (unit as parameterized for P0) mm/rev
in/rev
turns/"
MODULUS
X2 or
X2α
● Intermediate point 2 X ∅ (abs) or
● Intermediate point 2 in relation to X0 (inc) or
● Thread taper 1
Incremental dimensions: The sign is also evaluated
mm
Degrees
Z2
● Intermediate point 2 Z (abs) or
● Intermediate point 2 in relation to Z0 (inc)
mm
P2 Thread pitch 3 (unit as parameterized for P0) mm/rev
in/rev
turns/"
MODULUS
X3
● End point X ∅ (abs) or
● End point 3 in relation to X2 (inc) or
● Thread taper 3
mm
Degrees
Z3
● End point Z ∅ (abs) or
● End point with reference to Z2 (inc)
mm
LW Thread advance (inc) mm
LR Thread run-out (inc) mm
H1 Thread depth mm
DP or
αP
Infeed slope flank (inc) or infeed slope (angle)
mm
Degrees
● Infeed along a flank
● Infeed with alternating flanks
D1 or ND First infeed depth or number of roughing cuts - (only for ∇ and ∇ + ∇∇∇) mm
rev Finishing allowance in X and Z – (only for ∇ and ∇ + ∇∇∇) mm
NN Number of noncuts - (only for ∇∇∇ and ∇ + ∇∇∇)
