You use the configuration file to specify the selection of parameters in the list.
Software option
In order to be able to manage the parameter spindle direction of rotation, coolant
and tool-specific functions (M1-M4), you require the "ShopTurn/ShopMill" op‐
tion.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Tool change / block search in ShopMill program step
If a tool is inserted by a tool change in a ShopMill program step, the corresponding M function
for the coolant is automatically output.
After a block search, the coolant specified here is output even if a different coolant has been
programmed since, e.g. via G code or via the "Machine functions" window.
References
Information on the configuration and setting up of the tool list can be found in the following
references:
SINUMERIK Operate Commissioning Manual
Icons in the tool list
Icon/
Marking
Meaning
Tool type
Red "X" The tool is disabled.
Yellow triangle pointing
downward
The prewarning limit has been reached.
Yellow triangle pointing
upward
The tool is in a special state.
Place the cursor on the marked tool. A tooltip provides a
short description.
Green border The tool is preselected.
Magazine/location number
Green double arrow The magazine location is positioned at the change position.
Gray double arrow (con‐
figurable)
The magazine location is positioned at the loading position.
Red "X" The magazine location is disabled.
Tool management
13.5 Tool list
Milling
700 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
