The SELECT instruction selects a program for execution in a specific NC channel. The selected
program must be loaded into the working memory of the NC. The DISK parameter enables
the selection of external execution (CF card, USB data carrier, network drive).
<Program>
Absolute or relative path specification of the program to be selected.
Examples:
//NC/WCS.DIR/SHAFT.WPD/SHAFT1.MPF
SHAFT2.MPF
<Channel number>
Number of the NC channel in which the program is to be selected.
Example:
CH=2
[DISK]
Optional parameter for programs that are not in the NC memory and are to be executed
"externally".
Example:
SELECT //remote/myshare/shaft3.mpf CH=1 DISK
Comment
Comments are identified in the job list by ";" at the start of the line or by round brackets.
Template
You can select a template from Siemens or the machine manufacturer when creating a new
job list.
Executing a workpiece
If the "Select" softkey is selected for a workpiece, the syntax of the associated job list is checked
and then executed. The cursor can also be placed on the job list for selection.
Procedure
1. Select the "Program manager" operating area.
2. Press the "NC" softkey, and in directory "Workpieces" place the cursor
on the program for which you wish to create a job list.
3. Press the "New" and "Any" softkeys.
The "Any New Program" window opens.
4. Select entry "Job list JOB" from the "Type" selection field and enter a
name and press the "OK" softkey.
Managing programs
14.4 Creating a directory / program / job list / program list
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 763
