Parameters for teach-in of circle intermediate position CIP
Parameter Description
I Coordinate of the circle center point in the X direction
J Coordinate of the circle center point in the Y direction
K Coordinate of the circle center point in the Z direction
Transition types for teach-in of position and teach-in of G0 and G1, and ASPLINE
The following parameters are offered for the transition:
Parameter Description
G60 Exact stop
G64 Corner rounding
G641 Programmable corner rounding
G642 Axis-specific corner rounding
G643 Block-internal corner rounding
G644 Axis dynamics corner rounding
Motion types for teach-in of position and teach-in of G0 and G1
The following motion parameters are offered:
Parameter Description
CP Path-synchronous
PTP Point-to-point
PTPG0 Only G0 point-to-point
Transition behavior at the beginning and end of the spline curve
The following motion parameters are offered:
Parameter Description
Start
BAUTO Automatic calculation
BNAT Curvature is zero or natural
BTAN Tangential
End
EAUTO Automatic calculation
ENAT Curvature is zero or natural
ETAN Tangential
Teaching in a program
17.3 Inserting a block
Milling
852 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
