Tool management
6.7 Start-up of code carrier
HMI Advanced (IM4)
Commissioning Manual, 03/2009, 6FC5397-0DP10-3BA0
263
Cutting edge dialog data
The cutting edge dialog data is defined as follows:
Dialog
variable
Data type Designation Assignment $TC...
C1 Integer Subtype $TC_DP1
C4 Integer Length of cutting edge $TC_DP2
Geometry tool length compensation
C5 Double Length 1 $TC_DP3
C6 Double Length 2 $TC_DP4
C7 Double Length 3 $TC_DP5
Geometry tool radius compensation
C8 Double Length 1 $TC_DP8
C9 Double Length 2 $TC_DP9
C10 Double Radius 1 $TC_DP6
C11 Double Radius 2 $TC_DP7
C12 Double Angle 1 $TC_DP10
C13 Double Angle 2 $TC_DP11
Wear tool length compensation
C14 Double Length 1 $TC_DP12
C15 Double Length 2 $TC_DP13
C16 Double Length 3 $TC_DP14
Wear tool radius compensation
C17 Double Length 1 $TC_DP17
C18 Double Length 2 $TC_DP18
C19 Double Radius 1 $TC_DP15
C20 Double Radius 2 $TC_DP16
C21 Double Angle 1 $TC_DP19
C22 Double Angle 2 $TC_DP20
Base dimension/adapter dimension tool length
compensation
C23 Double Basic length 1 $TC_DP21
C24 Double Basic length 2 $TC_DP22
C25 Double Basic length 3 $TC_DP23
C26 Double Undercut angle $TC_DP24
C27 Integer Reverse insert $TC_DP25
C28 Cutting edge number for addressing variables -
C29 * Integer Downtime in minutes $TC_MOP2
C30 * Integer Prewarning limit for tool life in minutes $TC_MOP1
C31 Integer Number of pieces still to be produced $TC_MOP4
C32 Integer Prewarning limit for number of pieces still to be
produced
$TC_MOP3
C33 Double Set downtime in minutes $TC_MOP11
C34 Integer Unit quantity setpoint $TC_MOP13
