SIRIUS 3RT2 contactors/contactor assemblies
2.7 Accessories
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
191
2.7.9.2 Mounting
Prerequisite
The 3RT2926-4R..... coil terminal module must be mounted before you can attach the
coupling link.
CAUTION
Before mounting the coupling link, disconnect the voltage from L1 to L3.
Step Operating instruction Image
1 Attach the coupling link to the coil terminal
module using the two integrated mounting
pins.
2 Screw the coupling link tight with a
screwdriver.


