SIRIUS 3RF34 solid-state switching devices
3.11 Technical data
SIRIUS Innovations
358 System Manual, 01/2011, A8E56203870002-03
3.11.8 Solid-state contactors - main circuit, 2-phase controlled
Solid-state contactor, 2-phase controlled
Table 3- 39 Main circuit
Order no. 3RF34..- BB.4 3RF34..- BB.6
Controlled phases 2-phase 2-phase
Rated operational voltage
U
e
Operating range V 40 ... 506 40 ... 660
Rated frequency Hz 50 / 60 ± 10 % 50 / 60 ± 10 %
Rated insulation voltage
U
s
V 600 600
Rated impulse withstand voltage
U
imp
kV 6 6
Blocking voltage V 1200 1600
Voltage gradient V/μs 1000 1000
3.11.9 Solid-state contactors with control circuit
Solid-state contactor with control circuit
Table 3- 40 Control circuit A1 - A2:
Order no. 3RF34..- BB0. 3RF34..- BB2.
Method of operation DC operation AC operation
Rated control supply voltage
Us
V DC 24 acc to. EN 61131-2 AC 110 to 230
Rated control supply voltage, max.
Us
V DC 30 AC 253
Rated frequency of control supply voltage Hz — 50 / 60 ± 10 %
Typical actuating current mA 20 15
Response voltage V 15 90
Drop-out voltage V 5 < 40
Switching times
ï‚· ON-delay
ms 1 5
ï‚· OFF-delay
ms 1 + max. one half-wave 30 + max. one half-wave
