Siemens SIRIUS 3RF Series User Manual

SIRIUS 3RF34 solid-state switching devices
3.11 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
355
3.11.5 Solid-state contactors 3RF34, 3-phase, spring-loaded terminals
Solid-state contactors - instantaneous switching - 2-phase controlled
Table 3- 32 Rated operational voltage U
e
48 to 480 V
3RF3405-
1BB04
3RF3410-
1BB04
3RF3412-
1BB04
3RF3416-
1BB04
Connection type Spring-loaded terminals
Rated operational current I
e
A 5.2 9.2 12.5 16
Rated power at I
e
and U
e
400 V kW 2.2 4.0 5.5 7.5
Rated control supply voltage U
s
V DC 24 acc to. EN 61131-2
Weight approx. kg 0.250 0.380 0.380 0.380
Table 3- 33 Rated operational voltage U
e
48 to 480 V
3RF3405-
1BB24
3RF3410-
1BB24
3RF3412-
1BB24
3RF3416-
1BB24
Connection type Spring-loaded terminals
Rated operational current I
e
A 5.2 9.2 12.5 16
Rated power at I
e
and U
e
400 V kW 2.2 4.0 5.5 7.5
Rated control supply voltage U
s
V AC 110 to 230
Weight approx. kg 0.250 0.380 0.380 0.380
Table 3- 34 Rated operational voltage U
e
48 to 600 V, blocking voltage 1,600 V
3RF3405-
1BB06
3RF3410-
1BB06
3RF3412-
1BB06
3RF3416-
1BB06
Connection type Spring-loaded terminals
Rated operational current I
e
A 5.2 9.2 12.5 16
Rated power at I
e
and U
e
400 V kW 2.2 4.0 5.5 7.5
Rated control supply voltage U
s
V DC 24 acc to. EN 61131-2
Weight approx. kg 0.250 0.380 0.380 0.380
Table 3- 35 Rated operational voltage U
e
48 to 600 V, blocking voltage 1,600 V
3RF3405-
1BB26
3RF3410-
1BB26
3RF3412-
1BB26
3RF3416-
1BB26
Connection type Spring-loaded terminals
Rated operational current I
e
A 5.2 9.2 12.5 16
Rated power at I
e
and U
e
400 V kW 2.2 4.0 5.5 7.5
Rated control supply voltage U
s
V AC 110 to 230
Weight approx. kg 0.250 0.380 0.380 0.380
