SIRIUS 3RT2 contactors/contactor assemblies
2.8 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
277
2.8.4.5 Load side of 3RH2. contactor relays
Table 2- 118 Load side - 3RH2. contactor relays
Type 3RH2.
Size S00
Load side
Rated operational currents I
e
AC-12 A 10
Up to 230 V A 10
400 V A 3
500 V A 2
AC-15/AC-14 at rated operational voltage U
S
680 V 1
DC-12 at rated operational voltage U
S
24 V A 6
60 V A 6
110 V A 3
220 V A 1
440 V A 0.3
 1 current path
600 V A 0.15
24 V A 10
60 V A 10
110 V A 4
220 V A 2
440 V A 1.3
 2 current paths in series
600 V A 0.65
24 V A 10
60 V A 10
110 V A 10
220 V A 3.6
440 V A 2.5
 3 current paths in series
600 V A 1.8
DC-13 at rated operational voltage U
S
24 V A 6
60 V A 2
110 V A 1
220 V A 0.3
440 V A 0.14
 1 current path
600 V A 0.1
