SIRIUS 3RF34 solid-state switching devices
3.11 Technical data
SIRIUS Innovations
350 System Manual, 01/2011, A8E56203870002-03
3.11 Technical data
3.11.1 General data
Table 3- 23 Solid-state switching devices - General data
General data
Ambient temperature
Operation, derating as of 40 °C °C - 25 ... + 60
Storage °C - 55 ... + 80
Installation altitude m 0 ...1000;
at > 1,000 m seek advice from Technical Assistance
(www.siemens.com/lowvoltage/technical-assistance)
Shock resistance according to DIN IEC 60068-2-27 g /ms 15/11
Vibration resistance; acc. to DIN IEC 60068-2-6 g 2
Degree of protection IP20
Electromagnetic compatibility (EMC)
 Emitted interference acc. to DIN IEC 60947-4-2
- Conducted interference Class A for industrial environments
1)
- Emitted high-frequency interference
voltage
Class A for industrial environments
 Immunity
2)
- Electrostatic discharge acc. to
DIN IEC 61000-4-2 (corresponds to
severity 3)
kV Contact discharge: 4; air discharge: 8; behavior criterion 2
- Induced conducted RF fields
acc. to DIN IEC 61000-4-6
MHz 0.15 ... 80, 140 dBμV, behavior criterion 1
- High-frequency, electromagnetic
fields acc. to DIN IEC 61000-4-3
MHz 80 ... 3,000; test level 10 V/m; behavior criterion 1
- Burst acc. to DIN IEC 61000-4-4 kV 2/5.0 kHz; behavior criterion 2
- Surge acc. to DIN IEC 61000-4-5
3)
kV Conductor - protective conductor 2; conductor - conductor:
1; behavior criterion 2
Connection type

Solid-state contactor Screw-type and spring-loaded

Solid-state reversing contactor Screw-type connection system
