SIRIUS 3RA21/22 load feeders
6.6 Mounting
SIRIUS Innovations
594 System Manual, 01/2011, A8E56203870002-03
Mounting with a DIN rail adapter is also possible.
NOTICE
Vibration or shock load on size S00 reversing starters
In the case of vibration or shock load (such as in railway applications, for example), the
fuseless load feeder (size S00 reversing starter) has to be mounted on a DIN rail adapter to
protect the individual devices against damage.
Figure 6-1 Mounting on DIN rail without adapter
6.6.3.2 On DIN rail with DIN rail adapter
All feeders can be mounted on DIN rails with DIN rail adapters.
CAUTION
Possible damage to load feeder.
If the load feeder is mounted directly on the DIN rail without a DIN rail adapter, there is no
guarantee that the fastening will be vibration-proof.
Size S0 reversing starters have to be mounted with DIN rail adapters. However, DIN rail
adapters can be omitted when using busbar adapters.
