SIRIUS 3RV2 motor starter protectors
4.10 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
457
4.10.5 Auxiliary switches, transverse, solid-state compatible
1 CO contact
Rated operational voltage U
e
alternating voltage V 125
Rated operational current I
e
/AC-14 at U
e
= 125 V A 0.1
Rated operational voltage U
e
direct voltage L/R 200 ms V 60
Rated operational current I
e
/DC-13 at U
e
= 60 V A 0.3
V 5 Minimum load capacity
mA 1
4.10.6 Auxiliary switches, lateral and signaling switches
Switching capacity for different voltages:
Lateral auxiliary switch 1 NO + 1 NC, 2 NO, 2 NC, 2 NO +2 NC;
signaling switch
Rated operational current I
e
 AC-15, alternating voltage
- 24 V A 6
- 230 V A 4
- 400 V A 3
- 690 V A 1
 AC-12 = I
th
, alternating voltage
- 24 V A 10
- 230 V A 10
- 400 V A 10
- 690 V A 10
 DC, direct voltage L/R 200 ms
- 24 V A 2
- 110 V A 0.5
- 220 V A 0.25
- 440 V A 0.1
V 17 Minimum load capacity
mA 1
