SIRIUS 3RV2 motor starter protectors

4.9 Accessories

SIRIUS Innovations

System Manual, 01/2011, A8E56203870002-03

419

4.9.6 Disconnector module

4.9.6.1 Description

Disconnector module

The disconnector module is mounted on the motor starter protector on the infeed side. The

disconnector module can be used to form a visible isolating distance. To set up the isolating

distance, the plug connector is removed from the enclosure. The isolating plug can only be

removed with the supply disconnected.

The touch-proof isolating point is clearly visible and is secured with a padlock so that the

plug connector cannot be inserted during maintenance work, for example.

The disconnector module is compatible for use with all motor starter protector sizes.

Note

 The disconnector module cannot be used with 3RV27 and 3RV28 circuit breakers.

 The disconnector module covers the connection screws on the transverse auxiliary

switch. Therefore, if you are using the disconnector module, we recommend that you use

the lateral auxiliary switches or wait until the transverse auxiliary switches have been

wired before mounting the disconnector module.

 The disconnector module must not be used in conjunction with the 3-phase busbar

3RV1915.

4.9.6.2 Mounting

Mounting sequence

Note

Mounting sequence for disconnector module and transverse auxiliary switch

The disconnector module covers the connection screws on the transverse auxiliary switch.

Therefore, we recommend that you use the lateral auxiliary switches or wait until the

transverse auxiliary switches have been wired before mounting the disconnector module.
