SIRIUS 3RF34 solid-state switching devices
3.11 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
361
3.11.14 Solid-state reversing contactor with control circuit
Solid-state reversing contactor with control circuit
Table 3- 46 Control circuit A1 - A2:
Order no. 3RF34..- BD0. 3RF34..- BD2.
Method of operation DC operation AC operation
Rated control supply voltage
Us
V DC 24 acc to. EN 61131-2 AC 110 to 230
Rated control supply voltage, max.
Us
V DC 30 AC 253
Rated frequency of control supply voltage Hz — 50 / 60 ± 10 %
Typical actuating current mA 20 15
Response voltage V 15 90
Drop-out voltage V 5 < 40
Switching times
ï‚· ON-delay
ms 5 20
ï‚· OFF-delay
ms 5 + max. one half-wave 10 + max. one half-wave
ï‚· Locking time
ms 60 - 100 50 - 100
