SIRIUS 3RA28 function modules for mounting on 3RT2 contactors
7.6 Mounting
SIRIUS Innovations
668 System Manual, 01/2011, A8E56203870002-03
7.6.5 Replacing the removable terminal
DANGER
Hazardous Voltage
Will Cause Death, Serious Injury or Property Damage
Turn off and lock out all power supplying this device before working on this device.
Step Operating instruction Figure
1 Press the interlock.

2 Remove the terminal.

3 Attach the new terminal and press the
terminal into the device until the interlock
audibly engages.

