SIRIUS 3RV2 motor starter protectors
4.9 Accessories
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
421
4.9.6.3 Isolation and shut-off
Creating and securing the isolating distance
Table 4- 21 Creating and securing the isolating distance
Step Operating instruction Figure
1 Set the rotary button on the motor
starter protector to O.
2 Slide the closing lockout down.
3 Slide the isolating plug forward and
out of the disconnector module.




4 Slide the closing lockout up.
5 Secure the closing lockout so that the
isolating plug cannot be inserted or
pushed further in.




