SIRIUS 3RV2 motor starter protectors
4.9 Accessories
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
425
4.9.8.2 Mounting
Mounting the door-coupling rotary operating mechanism
min. 16 mm
max. 20 mm







Figure 4-8 Mounting the door-coupling rotary operating mechanism
Note
Remember to observe the mechanical coding of the connecting rod!
