SIRIUS 3RA21/22 load feeders
6.11 Dimension drawings (dimensions in mm)
SIRIUS Innovations
624 System Manual, 01/2011, A8E56203870002-03






Figure 6-11 S00 direct-on-line starter, AC/DC, hybrid connection system, link
module 3RA2911-2FA00
Note
The version of the fuseless load feeder (S00 direct-on-line starter, AC/DC) with hybrid
connection system is not available as a 3RA2 pre-assembled combination.







Figure 6-12 S00 reversing starter, AC/DC, screw-type connection system
3RA2210-..A
