163
DME wipe execution mode and pattern
numbers
The execution modes and pattern numbers supported in
each DME wipe pattern group are shown in the following
table.
Depending on the DME wipe pattern, there are patterns
th
at can be used for backgrounds (transition with
background selected for next transition) and patterns that
can be used for keys (transition with key selected for next
transition or independent key transition).
a: S
upported
×: Not supported
P in P (Picture-in-
picture)
In 1-channel mode:
Completed in two transitions.
In the first transition, the current
im
age shrinks, and the new image
appears behind it. In the second
transition, the current image expands
to its original size.
In 2-channel mode:
In the first half of the transition, the
cu
rrent image shrinks and the new
image appears behind it. In the
second half of the transition, the new
image expands, and the current
image disappears.
You can move the pattern from the
cu
rrent position by a relative amount.
During the transition, the signal from
the
utility 2 bus appears as the
background.
Mosaic In the first half of the transition, a
mo
saic is gradually applied so that
the current image switches to the
new image by the 50% point. In the
second half of the transition, the
mosaic effect on the new image is
gradually reversed, returning to the
original image at 100%.
Defocus In the first half of the transition, the
de
focus effect is gradually applied so
that the current image switches to the
new image by the 50% point. In the
second half of the transition, the
defocus effect on the new image is
gradually reversed, returning to the
original image at 100%.
Enhanced function mode DME
ch
annels can be used.
Crop Slide The current image is cropped in half
as
the new image appears,
displaying both images side by side.
Then, the cropped images slide
sideways to show only the new
image.
Brick In 2-channel mode:
A brick with visible side surface slides
in
over the current image, then
rotates so that the new image
becomes visible.
In 3-channel mode:
A brick appears over the current
imag
e, expanding and rotating, and
switches to the new image.
Resizer Slide Executes a Slide DME wipe using a
r
esizer.
Resizer Squeeze Executes a Squeeze DME wipe using
a r
esizer.
Resizer Frame I/O
Executes a Frame I/O DME wipe
using a resizer.
Pattern group Description
Pattern
group
Execution
mode
Pattern
number
Background
a)
Keys
b)
Slide 1ch 1001 to
1008
a a
2ch 2601 to
260
8
a ×
Squeeze 1ch 1021 to
103
3
a a
2ch 2621 to
262
8
a ×
Split 1ch 1011 to
101
3
a a
Door 1ch 1041 to
104
4
a a
Flip
Tum
ble
1ch 1101, 1102 a ×
Page
Turn
1ch 1301 to
131
3, 1315
to 1318,
1341 to
1345
a a
2ch 2701 to
271
3, 2715
to 2718,
2741 to
2745
a a
Roll 1ch 1321 to
133
3, 1335
to 1338,
1346 to
1350
a a
2ch 2721 to
273
3, 2735
to 2738,
2746 to
2750
a a
Frame
I/O
1ch 1201 to
120
9, 1221
to 1225
a a
2ch 2851 to
285
4, 2861
to 2864
a ×
P in P 1ch 1251 a ×
2ch 2651, 2652 a ×
