384
On: Set to Hold mode. The shifted state of the cross-
point buttons for all buses is enabled while the
[SHIFT ALL] button is pressed.
Off: Se
t to Lock mode. Each time the [SHIFT ALL]
button is pressed, the cross-points are switched
between the shifted and unshifted states for all
buses.
Assigning a Cross-Point
Assign Table
You can select a cross-point assign table to use for each
switcher bank or bus.
In the cross-point control block on the ICP-X7000, you
can c
hange the table assignment using the cross-point
assign table selection buttons in the cross-point pad. You
can also assign a different table to each cross-point button
row.
1
Open the Home > Setup > Xpt Assign > Table Assign
menu (19102.11).
2
Select the target switcher bank or bus to set.
To select and set multiple switcher banks/buses, place
a ch
eck mark beside the target switcher banks/buses
to set.
To select and set all switcher banks/buses, place a
chec
k mark in the Select All checkbox.
3
Press the [Table Assign] button and select a table
(Table1 to Table14) from the pull-down list.
Setting the logical V/K pair name table to
display on a panel
Press the [V/K Pair Panel Display] button and select a
logical V/K pair name table to display on a panel from the
pull-down list.
For details about logical V/K pair name tables, see
“Setting a Logical V/K Pair Name Table” (page 381).
Note
