26
• Center display:
State (displayed highlighted when on) and priority of
ke
y 1 to key 4
Main and sub assignment status when in multi program
2
mode (M, S)
• Right-side display:
State (displayed highlighted when on) and priority of
ke
y 5 to key 8
Main and sub assignment status when in multi program
2
mode (M, S)
c Tran
sition settings section (assignable buttons)
You can assign functions, such as selections and settings,
f
or transitions in the Home > Setup > Panel > Module >
Button Assign menu (19104.21).
For details about assigning buttons, see “Assigning
Control Panel Buttons” (page 402).
Next transition selection buttons
Transition type selection buttons
Wipe direction selection buttons
Transition preview buttons
Keyframe fader button
Pattern limit setting buttons
Main/sub switching buttons (multi program 2
mod
e)
Function
name
Button
name
Description
Background BKGD Switches the background for a
nex
t transition.
Key 1 to Key
8
KEY1 to
KEY8
Inserts or removes the selected
ke
y for a next transition.
The key is inserted if a key is
cu
rrently not inserted, or
removes the key if a key is
currently inserted.
Key Priority KEY
PRIOR
Changes the key priority for a
nex
t transition.
When the [PRIOR SET] button
is
lit, the setting for key priority
after the transition is used.
All ALL Selects multiple next transitions
si
multaneously.
Priority Set PRIOR
SET
Sets the key priority.
Function
name
Button
name
Description
Mix MIX Selects mix.
NAM NAM Selects NAM (non-additive
mix).
Super Mix SUPER
MI
X
Selects super mix.
Preset Color
Mi
x
PST
COLOR
MIX
Selects preset color mix.
Wipe WIPE Selects wipe.
DME Wipe DME
WIPE
Selects DME wipe.
FM 1&2 Clip
to FM 15&16
Clip
FM1&2
CL
IP to
FM15&16
CLIP
Selects clip transition.
Function
name
Button
name
Description
Normal NORM The wipe proceeds in the
d
irection from black to white of
the pattern images, shown in
“Wipe Pattern List” (page 491),
or in the direction of the arrows
(n
ormal).
Normal/
Re
verse
NORM/
REV
The wipe direction alternates
between normal and reverse
after each transition.
Reverse REV The wipe proceeds in the
o
pposite direction of normal
(reverse).
Function
name
Button
name
Description
Transition
Prev
iew
TRANS
PVW
Switches the transition preview
mode.
You can check a transition
u
sing preview output.
Function
name
Button
name
Description
KF KF Uses the fader lever as a
ke
yframe fader.
Function
name
Button
name
Description
Limit Set LIMIT SET Sets the pattern limit.
Pattern Limit PTN LIMIT Enables the pattern limit.
Function
name
Button
name
Description
Main MAIN Switches operation to the
fu
nction on the main side in
multi program 2 mode.
Simultaneously pressing the
[SUB]
button activates both the
main and sub operations.
Sub SUB Switches operation to the
fu
nction on the sub side in multi
program 2 mode.
Function
name
Button
name
Description
