Groundsmaster 4300--DPage 3 -- 6Kubota Diesel Engine
Air Cleaner
Figure 4
1. Air cleaner assembly
2. Indicator
3. Adapter
4. Spring
5. Hex nut
6. Bolt
7. Hose
8. Hose
9. Mount bracket
10. Air cleaner stand
11. Hose clamp (3 used)
12. Flange nut (8 used)
13. Cap screw (2 used)
14. Hose clamp (2 used)
15. Flange head screw (4 used)
16. Air cleaner mounting band
17. Spacer
18. Hose
19. Hose clamp
20. Flange head screw (2 used)
FRONT
RIGHT
VACUATOR
DIRECTION
2
3
6
8
9
10
11
13
1
5
7
12
14
15
16
17
18
19
4
12
11
11
Thread
Sealant
14
12 to 15 in--lb
(1.4 to 1.6 N--m)
12
12
20
