Groundsmaster 4300--DHydraulic System Page 4 -- 66
Hydraulic Pump Drive Shaft
1. Piston (traction) pump
2. Flange nut (2 used)
3. Flange head screw (2 used)
4. Guard hoop
5. Cap screw (2 used)
6. Engine flywheel
7. Cap screw (6 used)
8. Drive shaft assembly
9. Flange nut (4 used)
10. Flange head screw (2 used)
Figure 65
FRONT
RIGHT
34 to 42 ft--lb
(46to56N--m)
Antiseize
Lubricant
Permatex
Threadlocker
2
3
6
8
9
10
1
5
7
4
9
