Groundsmaster 4300--DHydraulic System Page 4 -- 64
Hydraulic Reservoir
1. Suction strainer
2. Tank cap
3. Hydraulic reservoir
4. Adapter
5. Manifold
6. O--ring
7. Hydraulic hose
8. O--ring
9. Cap screw
10. Flat washer
11. Bumper
12. Washer head screw (2 used)
13. Clamp (2 used)
14. Flange nut
15. Flange head screw (2 used)
16. O--ring
17. Hose clamp (2 used)
18. Hydraulic hose
19. Oil filter
20. Filter head
21. Hydraulic hose
22. O--ring
23. 90
o
hydraulic fitting
24. O--ring
25. Screen filter
26. Hydraulic fitting
Figure 64
FRONT
RIGHT
2
3
6
8
9
10
11
13
1
5
7
12
14
15
16
17
18
19
20
4
21
22
23
24
25
17
14
12
13
26 to 32 ft--lb
(36to43N--m)
105 to 115 ft--lb
(143 to 155 N--m)
22
24
26
26
