Groundsmaster 4300--D Hydraulic SystemPage 4 -- 25
Wheel Hub Puller
The wheel hub puller allows safe removal of the wheel
hub from the wheel motor shaft.
Toro Part Number: TOR6004
Figure 29
Measuring Container
Use this graduated container for doing hydraulic motor
efficiency testing (motors with case drain lines only).
Measureefficiencyofahydraulicmotorbyrestrictingthe
outlet flow from the motor and measuring leakage from
thec ase drain linewhile themotor ispressurized bythe
hydraulic system.
The table in Figure 31 provides gallons per minute
(GPM)conversion formeasured milliliterorounce leak-
age.
Toro Part Number: TOR4077
Figure 30
Figure 31
Hydraulic
System
