2GR-FE ENGINE MECHANICAL – ENGINE REAR OIL SEAL
EM–11
EM
ENGINE2GR-FE ENGINE MECHANICAL
ENGINE REAR OIL SEAL
COMPONENTS
DRIVE PLATE AND RING GEAR SUB-ASSEMBLY
ENGINE REAR OIL SEAL
FRONT SPACER
REAR SPACER
N*m (kgf*cm, ft.*lbf)
: Specified torque
Non-reusable part
83 (850, 61)
x8
A134930E01

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Toyota 2GR-FE and is the answer not in the manual?

Toyota 2GR-FE Specifications

General IconGeneral
ConfigurationV6
Displacement3.5 L (3, 456 cc)
Compression Ratio10.8:1
Fuel TypeGasoline
Bore x Stroke94 mm x 83 mm
ValvetrainDOHC, 4 valves per cylinder
Torque248-263 lb-ft
Oil Capacity6.4 quarts
