EM–66
2GR-FE ENGINE MECHANICAL – ENGINE UNIT
EM
10. REMOVE CYLINDER BLOCK WATER DRAIN COCK
SUB-ASSEMBLY
(a) Remove the water drain cocks from the cylinder
block.
(b) Remove the water drain cock plugs from the water
drain cocks.
11. REMOVE OIL FILTER ELEMENT
(a) Remove the drain plug.
NOTICE:
Do not remove the O-ring from the oil filter cap.
(b) Connect the hose to the pipe.
(c) Insert the pipe with the hose into the oil filter cap.
(d) Make sure that the oil is completely drained and
remove the pipe and O-ring.
RH Side:
LH Side:
A135829E01
A129666
Pipe
O-Ring
Pipe
Hose
Hose
A129667E01
To Next Page
