Toyota 2GR-FE - Starting System

2GR-FE STARTING – STARTING SYSTEM
ST–1
ST
ENGINE2GR-FE STARTING
STARTING SYSTEM
PARTS LOCATION
-ENGINE SWITCH
-STARTER CUT RELAY
TRANSMISSION
CONTROL ECU
without SMART KEY SYSTEM:
with SMART KEY SYSTEM:
INSTRUMENT PANEL J/B
ECM
PARK/NEUTRAL
POSITION SWITCH
MAIN BODY ECU
ENGINE ROOM R/B
-IGNITION RELAY
STARTER
-STARTER RELAY
-AM1 FUSE
-ST/AM2 FUSE
-ALT FUSE
-AM2 FUSE
-IGN FUSE
-IG2 FUSE
-IGNITION SWITCH
A135519E01
