60C5D11
5-12
1
2
3
4
5
6
7
8
9
Timing belt and sprockets
5
No. Part name Q’ty Remarks
1 Screw 1 M4
×
10 mm
2Bolt 3 M6
×
30 mm
3 Lighting coil 1
4Bolt 4 M6
×
30 mm
5 Lighting coil base 1
6 Dowel pin 1
7 Cover 1
8Screw 2
9 Screw 3 M6
×
20 mm
10 Neutral switch 1 Tiller handle model
11 Plate 1 Tiller handle model
12 Bracket 1 Tiller handle model
13 Bolt 2 M6
×
14 mm Tiller handle model
14 Hour meter 1
S60C5130
1
2
3
4
7
9
5
6
13
11
12
8
14
T
R
.
.
2 N
·
m (0.2 kgf
·
m, 1.4 ft
·
Ib)
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 2.9 ft
·
Ib)
10
Power unit / Timing belt and sprockets
