Yamaha F100B Service Manual

BRKT
Bracket unit
7-35
60C5D11
WARNING
Do not push the trim rams down while
installing them into the trim cylinders.
Otherwise, the power trim and tilt fluid
may spurt out from the unit.
Assembling the tilt ram
1. Install the new dust seal
1
, and O-rings
2
and
3
into the tilt cylinder end screw
4
.
2. Install the tilt cylinder end screw
4
to the
tilt ram
5
.
3. Hold the tilt ram end in a vise using alu-
minum plates on both sides.
4. Install new O-rings
6
and
7
into the tilt
piston
8
.
5. Install the balls
9
, absorber valve pins
0
, and spring
A
as shown.
6. Install the tilt piston
8
, washer
B
, and
nut
C
to the tilt ram
5
, and then tighten
the nut to the specified torque.
Trim & tilt wrench: 90890-06548
T
R
.
.
Trim cylinder end screw
5
:
80 N·m (8.0 kgf·m, 58 ft·lb)
S60C7565
AA
T
R
.
.
Tilt piston nut
C
:
100 N·m (10 kgf·m, 72 ft·lb)
