Yamaha F100B Service Manual

LOWR
Lower unit
6-23
60C5D11
6. Install the O-ring
A
and insert cartridge
B
into the pump housing
C
.
NOTE:
Align the insert cartridge projections
b
with
the holes
c
in the pump housing.
7. Install the O-ring
D
and pump housing
assembly
E
into the lower case, tighten
the bolts
F
, and then install the seal
G
and cover
H
.
NOTE:
• When installing the pump housing, apply
grease to the inside of the housing, and
then turn the drive shaft clockwise while
pushing down the pump housing.
• Align the cover
H
projection
d
with the
hole
e
in the pump housing.
Installing the lower unit
1. Set the gearshift to the neutral position at
the lower unit.
2. Install the two dowel pins
1
to the lower
unit.
3. Install the lower unit to the upper case,
and then tighten the bolts to the specified
torque.
S60C6075
AA
S60C6080
AA
LT
572
S60C6275
N
