CHK
ADJ
Periodic checks and adjustments
3-9
60C5D11
È
F100B
É
F100C
2. Place the lower unit in water, and then
start the engine.
3. Check for water flow at the cooling water
outlet. If there is no water flow, check the
cooling water passage inside the out-
board motor.
Control system
3
Checking the throttle cable operation
1. Check that the throttle control lever
1
touches the fully closed stopper
a
when
the remote control lever is in neutral or
the throttle grip is fully closed. Adjust the
throttle cable length, if necessary, as fol-
lows.
2. Loosen the locknut
2
, remove the clip
3
, and then disconnect the throttle cable
joint
4
.
3. Contact the throttle control lever
1
with
the fully closed stopper
a
.
4. Adjust the position of the throttle cable
joint until its hole is aligned with the set
pin
b
on the throttle control lever.
S60C3370
S60C3350
S60C3360
S60C3390
S60C3400
