Built-in
1. Loosen the manual valve by turning it
counterclockwise until it cannot be turned
further.
2. Fully tilt the outboard motor up, and then
release it and let it lower by its own
weight four to five times.
3. Tighten the manual valve by turning it
clockwise.
4. Let the fluid settle for 5 minutes.
5. Push and hold the power trim and tilt
switch in the up position until the out-
board motor is fully tilted up.
6. Support the outboard motor with the tilt
stop lever, and then let the fluid settle for
5 minutes.
WARNING
After tilting up the outboard motor, be
sure to support it with the tilt stop lever.
Otherwise, the outboard motor could sud-
denly lower if the power trim and tilt unit
should lose fluid pressure.
7. Remove the reservoir cap
1
, and then
check the fluid level in the reservoir.
8. If necessary, add sufficient fluid of the
recommended type to the correct level.
NOTE:
The fluid level should be at the brim of the
filler hole.
9. Install the reservoir cap.
NOTE:
Repeat this procedure until the fluid remains
at the correct level.
Recommended power trim and tilt
fluid:
ATF Dexron
II
S60C7715
Bleeding the power trim and tilt unit (F100B)
