POWR
Power unit
5-33
60C5D11
Installing the valves
1. Install the new valve stem seal
1
to the
valve guide.
2. Install the valve
2
, spring seat
3
, valve
spring
4
, and spring retainer
5
in the
sequence shown, and then attach the
special service tool.
3. Compress the valve spring, and then
install the valve cotter
8
using a thin
screwdriver with a small amount of
grease applied to it.
4. Lightly tap the spring retainer with a plas-
tic hammer to set the valve cotter
securely.
5. Install the valve pads and valve lifters.
Valve spring compressor
6
:
90890-04019
Valve spring compressor attachment
7
:
90890-06320
S60C5660
E
S60C5680
S60C5690
