Yamaha F100B Service Manual

60C5D11
7-20
1
2
3
4
5
6
7
8
9
Installing the upper case
1. Install the upper mount
1
and bolts
2
into the upper case.
2. Install the bolts
3
, and then tighten them
to the specified torque.
3. Install the lower mounts
4
to the upper
case.
4. Install the mount cover
5
.
5. Install the upper and lower mounting
bolts into the swivel bracket
6
simulta-
neously.
6. Install the upper mounting nut
7
and
lower mounting nut
8
, and then tighten
them to the specified torques.
NOTE:
Before tightening the lower mounting nut, be
sure to connect the ground lead to the lower
mounting bolt.
7. Install the oil pump assembly
9
.
T
R
.
.
Muffler assembly bolt
B
:
20 N·m (2.0 kgf·m, 14 ft·lb)
T
R
.
.
Upper mount bolt
3
:
26 N·m (2.6 kgf·m, 19 ft·lb)
S60C7100
LT
572
LT
572
A
S60C7105
LT
572
LT
572
A
T
R
.
.
Upper mounting nut
7
:
53 N·m (5.3 kgf·m, 38 ft·lb)
Lower mounting nut
8
:
73 N·m (7.3 kgf·m, 53 ft·lb)
Oil pump bolt
0
:
11 N·m (1.1 kgf·m, 8.0 ft·lb)
S60C7110
AA
Upper case (F100B)
