ZXR10ZSRV2HardwareDescription

PropertyDescription

OperationalmodeFullduplex

AppliedstandardIEEE802.3zGigabitEthernetstandard

SupportedframeformatEthernetframe

Supportednetwork

protocol

Indicators

ForadescriptionoftheindicatorsoftheRAC-PIU-09GE-8E1SFPboard,refertoT able

9-76.

Table9-76DescriptionoftheIndicatorsonthePaneloftheRAC-PIU-09GE-8E1SFP

Board

IndicatorColorDescription

RUNGreenTheindicatorislitwhentheboardisoperatingproperly.

ALMRedTheindicatorislitiftheboardproducesanalarm.

Electricalport

indicator

Green/YellowLinkstatus/datatransmissionindicatorsforfourGEelectrical

interfaces:

lIfthelinkisnormal,therightgreenindicatorislit.

lIfdataisbeingtransmitted,theleftyellowindicatorashes.

lIfthereisnodatabeingtransmittedornoconnection,the

indicatorsarenotlit.

LNK/ACTGreen/Yellow

Linkstatus/datatransmissionindicatorsfortheGEoptical

interface:

lIfthelinkisnormal,theindicatorislitingreen.

lIfdataisbeingtransmitted,theindicatorashesinyellow.

lIfthereisnodatabeingtransmittedornoconnection,the

indicatorisnotlit.

TechnicalParameters

ForthetechnicalparametersoftheRAC-PIU-09GE-8E1SFPboard,refertoT able9-77.

Table9-77TechnicalParametersoftheRAC-PIU-09GE-8E1SFPBoard

ParameterSpecication

SilkscreennameRAC-PIU-09GE-8E1SFP

Dimensions(W×H×D)7.76in.×0.79in.×6.9in.(197.2mm×19.92mm×175mm)

Powerconsumption12W

Weight1.19lb.(0.54kg)

Rate1GE×9

9-40

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
