ZXR10ZSRV2HardwareDescription
lSupportsboardinformationqueryandtemperaturemonitoring.
lSupportsthe75Ωor120Ωconguration.
TheboardprovidesjumpersX6,X9,andX10toconguretheinterfaceresistanceto
75Ωor120Ω.Bydefault,theinterfaceresistanceis75Ω.Fortheinterfaceresistance
conguration,refertothefollowingtable.
Jumper75Ω120Ω
X62-3:ON1-2:ON
X9andX10ONOFF
Caution!
Thejumpercongurationcanbeperformedbyprofessionalsonly.
Panel
ForthepaneloftheRAC-PIU-16CE1board,seeFigure9-15.
Figure9-15FrontPaneloftheRAC-PIU-16CE1Board
InterfaceProperties
FortheinterfacepropertiesoftheRAC-PIU-16CE1board,refertoTable9-43.
Table9-43InterfacePropertiesoftheRAC-PIU-16CE1Board
PropertyDescription
ConnectortypeDB50
OperationalmodeFullduplex
AppliedstandardITU-TG.703,G.704
SupportedlinkprotocolPPP ,ML-PPP ,HDLC,FR
Supportednetwork
protocol
IP
Indicators
ForadescriptionoftheindicatorsoftheRAC-PIU-16CE1board,refertoT able9-44.
9-24
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
